Cone crusher liner

Product Introduction

The cone crusher liner is one of the important parts of cone crusher. With the framework, horizontal axis, moving cone, balance wheel, eccentric sleeve, Lower crushing wall, hydraulic coupling, lubrication system, hydraulic system, and control system, it forms cone crusher. All kinds of cone crusher liner can be customized according to the drawings provided by the customers.

1. Since the cone crusher liner is connected by casting zinc alloy, it need to check its firm condition after the operation for a period of time. The connection of the cone crusher liner and the adjusting ring is fixed by the U-type fixed screw, and the casting zinc alloy in the center of the cone crusher and the adjustment ring makes it close together.

2. When changing a new cone crusher liner, it is important to check its firm or not, and after the installation, it also need to pay attention to the operation after a period of time to check its strong degree and make sure it's not loose, and can be fixed by screw.



The Great Wall machinery produces various types of high manganese steel moving cone and fixed cone for cone crusher, including ordinary high manganese steel material: manganese13 (Mn13), manganese13 Chromium2 (Mn13Cr2) and super manganese steel material: manganese18 (Mn18), manganese 18 Chromium 2 (Mn18Cr2).

1. Adopt high manganese steel material with good toughness, low price and high cost performance;

2. Good wear resistance and long service life;

3. Strong production strength, short casting cycle and high capacity of Great Wall machinery

cone crusher liner

Model Parameter

Model Cacity shape (mm) Min discharge setting (mm) Max Feding size (KW) Power Opening cycle, closed edge drainage and corresponding production capacity (t/h)
10mm 13mm 16mm 19mm 25mm 31mm 38mm
SDY900B Fine type 9 87 75 46 59 73 82
Thic 13 150 75   59 73 91 118 137 164
k type
Super thick type 25 155 75         128 147 175
SDY1300B Fine type 13 120 200   109 127 146 163 181
Thic 16 180 200     132 159 200 228 253
k type 19 205 200       173 218 250 295
Super thick type 25 220 200         237 273 324
SDY1700B Fine type 16 180 250     182 205 259 296 327
Thic 22 205 250         291 337 381
k type 25 230 250         354 417 454
Super thick type 38 315 250             538
SDY2200B Fine type 19 235 400       381 499 617 726
Thic 25 280 400         608 726 807
k type 31 310 400           789 844
Super thick type 38 460 400             880

Chaeng Cases

The cone crusher liner technology is very mature for CHAENG, and it has been used in many large domestic cement, mines, building materials, chemical industry and other large enterprises, which is deeply favored by customers.

Welcome to order HP300, HP400, HP500 and other models of the cone crusher liner from Great Wall machinery.

cone crusher liner

Founded in 1958 and located in Xinxiang, Henan province, CHAENG has 60-year experience in equipment manufacturing with an area of 330,000 m2 and 1 billion RMB of annual production value. The company is specialized in manufacturing ball mills, rotary kilns, vertical mills, large steel casting and can undertake the EPC projects of cement production lines, active lime production lines, blast furnace slag/ steel slag/ nickel slag grinding plants. Its products are sold to more than 50 countries and regions in Southeast Asia, Central Asia, South Asia, North America, South America and Europe.

Our long-term strategic partners: Arcelor Mittal, Tata Group, Pohang Iron and Steel Company, Germany CCE, Japan Chiba , Shanghai Baosteel,Voestalpine and Aosen steel.
